Power Supply
Cooler Master MWE 750 White 750W SMPS
Availability:
Out of stock
- 80 PLUS Standard Certified
- 120 mm HDB Fan
- DC-to-DC + LLC Circuit Design
- Single +12V Rail
- Silent Mode
- Flat Black Cables
Note : * Store Price may be vary *
5,700 8,199
Out of stock
Technical Details
| MODEL | MPE-7501-ACABW-IN |
| SERIES | MWE Series |
| 80 PLUS | Standard |
| MODULAR | Non Modular |
| ATX VERSION | ATX 12V Ver. 2.52 |
| PFC | Active PFC |
| INPUT VOLTAGE | 200-240Vac |
| INPUT CURRENT | 6A |
| INPUT FREQUENCY | 50-60Hz |
| DIMENSIONS | 140(L) x 150(B) x 86(H) mm |
| FAN SIZE | 120mm |
| FAN BEARING | HDB |
| FAN SPEED | 2400 RPM |
| NOISE LEVEL @ 20% | 11.12 dBA |
| NOISE LEVEL @ 50% | 20.3 dBA |
| NOISE LEVEL @ 100% | 39.5 dBA |
| EFFICIENCY | 85% Typically |
| 80 PLUS RATING | 80 PLUS Standard 230V EU |
| ERP 2014 LOT 3 | Yes |
| OPERATING TEMPERATURE | 40°C |
| POWER GOOD SIGNAL | 100-500ms |
| HOLD UP TIME | >14ms at 100% full load@230Vac |
| MTBF | >100,000 Hours |
| PROTECTIONS | OVP, OPP, SCP, UVP, OTP |
| REGULATORY | CCC, CE, TUV-RH, EAC, RCM, cTUVus, FCC, BSMI, KC, CB |
| ATX 24-PIN CONNECTORS | 1 |
| EPS 4+4 PIN CONNECTORS | 1 |
| EPS 8 PIN CONNECTOR | 1 |
| SATA CONNECTORS | 6 |
| PERIPHERAL 4-PIN CONNECTORS | 3 |
| PCI-E 6+2 PIN CONNECTORS | 4 |
| WATTAGE | 500 to 750W |
Brand
Cooler Master
