Number of NozzlesTotal 1,472 nozzles
Ink Bottles (Type/Colours)GI-790 (Pigment Ink/Black), (Dye-based Ink/Cyan, Magenta, Yellow)
Print HeadsBH-7, CH-7
Maximum Print Resolution4,800 (horizontal)*1 x 1,200 (vertical) dpi
Document (ESAT/Simplex)8.8 / 5.0 ipm (mono/colour)
Document (FPOT Ready/Simplex)11 / 17 s (mono/colour)
Photo (4 x 6") (PP-201 / Borderless)60 s
Printable WidthUp to 203.2 mm (8 inch)
Borderless: Up to 216 mm (8.5 inch)
Borderless PrintingTop/Bottom/Left/Right margin: 0 mm
Bordered PrintingLTR, LGL:
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 6.4 mm, Right margin: 6.3 mm
Others:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 3.4 mm
Rear TrayPlain Paper (64 - 105 g/m²)
High Resolution Paper (HR-101N)
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Plus Semi-Gloss (SG-201)
Matte Photo Paper (MP-101)
Envelope
Paper SizeA4, A5, B5, LTR, LGL, Envelope (COM10, DL), 10.16 x 15.24 cm (4 x 6"),
12.7 x 17.78 cm (5 x 7"), 20.32 x 25.40 cm (8 x 10"), Square (127 x 127 mm), Business Card
[Custom Size] Width: 55 - 215.9 mm, Length: 89 - 676 mm
Rear TrayPlain Paper (A4, 64 g/m²): 100
High Resolution Paper (HR-101N): 80
Photo Paper Plus Glossy II (PP-201, 4 x 6"): 20
Photo Paper Plus Semi-Gloss (SG-201, 4 x 6"): 10
Matte Photo Paper (MP-101, 4 x 6"): 20
Envelope (COM10, DL): 10
Scanner Type / TechnologyFlatbed (Platen) / Contact Image Sensor (CIS)
Optical Resolution600 x 1,200 dpi
Greyscale16 bit / 8 bit
Colour48 bit / 24 bit (RGB each 16 bit / 8 bit)
Document (Colour):
(sFCOT) / (sESAT)32 s / 1.7 ipm
Multiple CopyMax. 20 pages
System RequirementsWindows 10 / 8.1 / 7 SP1
(macOS is not supported)
Operation Panel3.04 cm (1.2 inch) LCD Segment Mono
InterfaceUSB 2.0
Power Consumption OFF / Standby0.2 W / 0.6 W
Operation9 W
Dimensions (W x D x H)445 x 330 x 163 mm
Weight6.3 kg
Page Yield (Plain Paper)GI-790 PGBK: 6,000 pages
GI-790 C, M, Y: 7,000 pages
