Technical Details
Model | RR-S4NA-17PA-R1 |
CPU Socket | Intel LGA1700, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156
AMD AM5, AM4 |
Heat Sink Dimensions (L X W X H) | 124 x 73 x 152 mm / 4.8 x 2.8 x 5.9 Inch |
Heat Sink Material | Direct Contact, Aluminum Fins, 4 Heat Pipes |
Fan Dimensions (L X W X H) | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
Fan Quantity | 1 PCS |
Fan Led Type | ARGB |
Fan Speed | 650-1750 RPM (PWM) ± 10% |
Fan Airflow | 71.93 CFM (Max) |
Fan Air Pressure | 1.86 mmH2O (Max) |
Fan MTTF | >160,000 Hours |
Fan Noise Level | 27.2 dBA |
Fan Bearing | Rifle |
Fan Power Connector | 4-Pin (PWM) |
Fan Rated Voltage | 12VDC |
Fan Rated Current | 0.26A |
Fan Safety Current | 0.37A |
Fan Power Consumption | 3.12W |
Warranty | 2 Years |
ARGB AUTO DETECTION
Intuitive LED detection automatically provides default ARGB spectrum lighting or full ARGB customization via 3-pin header connection.
SPECTRUM ARGB FAN
Performance spectrum fan with ARGB compatibility with Asus Aura, ASRock RGB, Gigabyte and MSI RGB motherboards.
NICKEL PLATED HEAT PIPES
4 heat pipes with silver nickel plated finish provide exceptional cooling and aesthetics
WIDE RANGE COMPATIBILITY
Compact 152m height designed for wide chassis compatibility without sacrificing performance
UPGRADED INSTALLATION BRACKETS
Redesigned brackets simplify installation on the latest available platforms
