ModelIntel i5 4th
Max Memory Size (dependent on memory type)32 GB
Memory TypesDDR3L 1333/1600
Max # of Memory Channels2
Max Memory Bandwidth25.6 GB/s
ECC Memory Supported ‡No
GPU Name‡Intel® HD Graphics 4600
Graphics Base Frequency400 MHz
Graphics Max Dynamic Frequency1.15 GHz
Graphics Video Max Memory2 GB
Graphics OutputeDP/DP/HDMI/VGA
Max Resolution (HDMI)‡3840x2160@60Hz
Max Resolution (DP)‡3840x2160@60Hz
Max Resolution (VGA)‡2880x1800@60Hz
DirectX* Support11.2/12
OpenGL* Support4.3
Intel® Quick Sync VideoYes
Intel® InTru™ 3D TechnologyYes
Intel® Clear Video HD TechnologyYes
# of Displays Supported ‡3
Device ID0x416
PCI Express Revision3
PCI Express Configurations ‡1x16 or 2x8 or 1x8 2x4
Max # of PCI Express Lanes16
Sockets SupportedFCBGA1364
Max CPU Configuration1
TJUNCTION100 C
Package Size37.5mm x 32mm x 1.65mm
Intel® Turbo Boost Technology ‡2.0
Intel® Hyper-Threading Technology ‡Yes
Intel® Transactional Synchronization ExtensionsNo
Intel® 64 ‡Yes
Instruction Set64-bit
Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Identity Protection Technology ‡Yes
Intel® Secure KeyYes
Intel® AES New InstructionsYes
Intel® Trusted Execution Technology ‡No
Execute Disable Bit ‡Yes
Anti-Theft TechnologyYes
Intel® Virtualization Technology (VT-x) ‡Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
Intel® VT-x with Extended Page Tables (EPT) ‡Yes
