Capacities1TB
Form FactorM.2 2280
InterfacePCIe Gen4x4
Speed1TB: Read speed up to 7400MB/s1, write speed up to 6500MB/s1,
random read up to 1,000,000 IOPs, random write up to 900,000 IOPs
Operating Temperature0°C to 70°C (32°F to 158°F)
Storage Temperature-40°C to 85°C (-40°F to 185°F)
Dimensions (L x W x H)512GB-4TB:80 x 22 x 2.45 mm (3.15” x 0.87” x 0.10”)
8TB: 80 x 22 x 3.75 mm (3.15” x 0.87” x 0.148”)
Weight512GB-4TB:6g / 0.013 lbs
8TB: 7.6g / 0.017 lbs
WarrantyFive-year limited warranty
Shock-resistant1500G, duration 0.5ms, Half Sine Wave
Vibration-resistant10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X,Y,Z)
TBW1TB: 1000TBW
MTBF1,500,000 Hours
